Anti-Slip Waterproofing Application Cross Laminated Film
Description:
It is a high-strength multi-layer composite film,It is made of HDPE
as the base material, adding plasticizer, plasticizer, stabilizer,
antioxidant, UV absorber, toughener and other additives through
multi-layer co-extrusion blow molding into embryos, and then by
multiple pull Stretching, then rotary cutting into a film substrate
with a horizontal and vertical distribution of 45 °, and finally
through cross-compositing. Due to its cross-stacking structure is
different from ordinary single-layer or multi-layer film, it has
the thermal stability, dimensional stability, two-way tear
resistance, two-way uniform tension and high elongation which are
not available in traditional films.
Advantages:
- Excellent dimensional stability. It can fix its own size without
deformation.
- Two-way tear resistance. The vertical and horizontal mesh structure
effectively solves the phenomenon of easy wrinkling and drumming
after construction
- Performance against UV radiation. The use of outdoor high
temperature conditions is guaranteed.
- High strength and high elongation performance. Excellent resistance
to high and low temperature.
Unique puncture resistance, self-healing and continuous tear
resistance and excellent nail water tightness.
Application:
A cross-laminated polyolefin that is taken to new levels of
performance. After countless iterations in our lab, we created a
film that features outstanding strength, a heightened spectrum of
resistances in many categories, and much more. In fact, you have
probably already used a tag, label, or package made with award
winning Cross Laminated Film, as it can be found in electrical cord
labels, pilfer-resistant flexible packaging, pool chemical
packaging, and construction waterproofing membranes.
Parameter:
| NO. | Item | Performance |
| | SDM-30 | SDM-60 |
| 1 | Tensile Property | Tensile Strength/Mpa ≥ | 30 | 50 |
| | MaxF/(N/50mm) ≥ | 200 | 300 |
| | Elongation as MaxF/% ≥ | 200 |
| | Elongation at break/% ≥ | 250 |
| 2 | Sample number of no broken tested by free-falling dart method ≥ | 8 |
| 3 | Tear Strength(Nail Shank)/N ≥ | 60 |
| 4 | Angle Tear Strength/N ≥ | 25 |
| 5 | Thermal Stability | 120 ℃,10min, No bulb, No deformation |
| 6 | Cryogenic Flexibility ℃ | -35℃, No fissure, No delamination |
| 7 | Thermal Ageing | Appearance | No bulb, No deformation |
| | Subsequent MaxF/% ≥ | 80 |
| | Elongation at MaxF/% ≥ | 200 |
| | Elongation at break/% ≥ | 200 |
| 8 | Artificial Weathering | Appearance | No bulb, No deformation |
| | Subsequent MaxF/% ≥ | 70 |
| | Elongation at MaxF/% ≥ | 180 |
| | Elongation at break/% ≥ | 180 |
About Upass:
| Upass, founded in 2008, is headquartered in New Materials Industrial Park, Qingpu
District, Shanghai, and has two production bases in Taicang,
Jiangsu and Chenzhou, Hunan. Now as a governing unit of China Building Waterproof Association, a
vice chairman unit of Professional Committee of China Modified
Plastic Association, an enterprise with Triple A credibility in
China Plastic Association, not only assists the development of the
relevant industries, but also upholds the conception of sustainable
development by successive technological innovation. Upass so far
has acquired over 100 of intellectual property rights. |
| UPASS will spare no effort in strengthening and improving the
production, sales networks, service system to return the trust and support of customers, and look forward to
working with you in a win-win future. |
Company History:
Main Fields:
As a new material field, functional films are also one of the top
ten key fields of Made in China 2025,
and the awareness in the market is increasing. Nowadays, functional
films are not only used in the
construction field, special packaging, tape, label, automobile,
electronics and other industries,
but also in the fields of film filtration, air permeable film,
graphene heating film, insulation film,
Anti-UV film, biodegradable materials etc..
UPASS, as a leading domestic deep cultivator of polymer functional
films, has also entered a stage
of rapid development. We believe that UPASS will enter more
application fields of polymer films in
near future.
