HDPE 0.09mm 90 Micron Polyethylene Construction Film

Ask Lasest Price
Brand Name :	Upass
Model Number :	Laminated Film
Certification :	CE, ROHS
Price :	Negotiable
Payment Terms :	T/T,L/C
Supply Ability :	200,000㎡~300,000㎡
Delivery Time :	15days

Add to Cart

Product Details
Company Profile

HDPE 0.09mm 90 Micron Polyethylene Construction Film

Aging Resistance High Density Polyethylene Anti Corrosion Film

Description:

It is specially designed for waterproofing industry, which shall substitute conventional exposed waterproofing material including the film for waterproofing membrane. It also has cost effectiveness, and lasts over 25years of weather resistance.

Application:

It is used as surface material for self-adhesive, SBS waterproofing membranes and tapes.

Structure:

The green side, it is high strength cross laminated film;

The white side is fluorine film (Aging or Weather resistance).

Weather Resistance Tape Application:

Aging Resistance Waterproof Membrane Application:

Advantages:

1. Excellent properties of anti-aging

2. UV resistance

3. Weather resistance

4. Chemical corrosion resistance

5. Resistance to high temperature,heat,humidity and extreme cold

6. Reflectivity of over 85%

7. High strength, tear resistance

Parameter:

Detection Item		Detection Method	Detection Value	Remark
Thickness	UF509	GB/T6672-2001	0.128mm	/
Width		GB/T6673-2001	/	According to customer needs
Max force	UF509	GB/T 328.9-2007	MD:324N	Rectangular spline, spline width 25mm, stretching rate: 100mm / min, fixture gauge distance: 100mm
			TD:348N
Elongation at Break	UF509		MD:406%
			TD:260%
Tensile Strength	UF509	GB/T 529-2008	MD:47N	Stretching speed:250mm/min
			TD:43N
Surface Tension		GB/T14216	≧42dyn/cm	Dyne Pen Test
Dimensional change rate	UF509	GB/T 35467-2017	MD:0.96%	90℃&24h
			TD:0.77%
Water vapor transmission rate		GB/T 21529	≦70 g/m2.24h (20um)	38℃+100%RH
				Electrolytic sensor method
Flammability grade		UL94	VTM-0	White weathering film
Aging test	PCT96	/	Yellowing index △b≤2.0,	Temperature 121 ℃, humidity 100%, air pressure 2atm, time 48h
	UV300KWh	IEC61215		The temperature of the sample is 60 ± 5 ℃, and the total exposure is 120KWh • m2, of which UVB accounts for 3% -10%.
	DH2000h	IEC61215		Temperature 85 ℃, humidity 85% R.H., 2000h
	TC400	IEC61215		Temperature －40 ℃ ～ 85 ℃, 6h / cycle, 400cycle

About UPASS:

Upass, founded in 2008, now as a governing unit of China Building Waterproof Association,

a vice chairman unit of Professional Committee of China Modified Plastic Association,

an enterprise with Triple A credibility in China Plastic Association, not only assists the

development of the relevant industries, but also upholds the conception of sustainable

development by successive technological innovation. Upass so far has acquired over

100 of intellectual property rights.
