ISO9001 0.15mm 150 Micron Silicone Coated Release Liner

Ask Lasest Price
Brand Name :	UPASS
Model Number :	Release Film
Certification :	ISO9001
Price :	Negotiable
Payment Terms :	TT/LC
Supply Ability :	600 Tons/Month
Delivery Time :	Negotiable

Add to Cart

Product Details
Company Profile

ISO9001 0.15mm 150 Micron Silicone Coated Release Liner

PET Release Liner

Description:

Product Name	PET Release Liner
Color	Transparent, Milky White or as your request
Thickness(um)	12/25/30/36/50/75/100/125/188/250 or As Your Request.
Release Force	5g-8g or As Your Request
Residual Rate	More than 90%
Usage	Tape and Die-cutting,Lable and Printing,Carbon Material Application,Medical Sanitary,Optics Application.
QC	Strict quality control under ISO9001. Our QC department strictly carries on a precise process to ensure best quality.
Certificates	ROHS; CQC; SGS; ISO9001:2015;
Sample	Free samples & Freight Charges will be returned after deal.
Package	Roll is packed with air bubble film , on fumigation wooden pallet.
Payment	T/T, L/C
Others	Special size,color can be made according to customer's requirement.

PET release film is also called PET silicone oil film. A layer of silicone oil is applied on the

surface of the PET film to reduce the adhesion of the PET film surface and achieve the release effect.

Can be divided into single-sided release film and double-sided release film.

According to the release force, it can be divided into a light release film, a medium release film, and a heavy release film.

Our company is equipped with a quick slitting machine that can be divided and sliced according to customer specifications.

Features:

► High temperature resistance, up to 180℃
► Easy peel off when remove the release film
► High residual adhesiveness rate(≥90%) to prevent the influence of silicon transfer on products
► Make products' surface more flat

Applications:

♦ Used for self-adhesive waterproof membranes and other waterproof materials, adhesive tapes
♦ Used for cables production, packaging materials
♦ Used for cast materials, electronic applications, ceramic capacitors, window materials. printing, electronic, advertisements

Phameter:

Products Name		PET release film		Spec.	0.023mm*1000mm
Detection Methed		Q/TPXP 1-2013		Date	2020.9.26
NO.	Item	Factory Requirement		Detection Value	Individual Determination
1	Appearance	No bubbles, no stains, no damage, no impurities		Qualified	Qualified
2	Spec.	Width	1000±5mm	1001	Qualified
		Thickness	0.023±0.005mm	0.023	Qualified
3	Max.F (N/50mm)	TD (CD)	≥150	192	Qualified
		MD	≥150	156	Qualified
4	Elongation (%)	TD (CD)	≥40	87	Qualified
		MD	≥40	56	Qualified
5	Tensile Strength(Mpa)	TD (CD)	≥30	124	Qualified
		MD	≥30	108	Qualified
6	Subsequent Adhesion	%	≥90	92	Qualified
Detection		Qualified

FAQ:

1.What's the payment terms and trade terms for new customers?
Payment terms:30% T/T desposit payment in advance, balance 70% before shipment or against copy of B/L. L/C are acceptable.

2. Are you factory or trading company?
We are a manufacturers with two production plants in Jiangsu and Hunan.

3. What about the lead time?
Within 2 weeks, if the order quantity is large, the time will be more than 20 days.

4.May I get some free sample for trial?
As our company policy, we are able to provide free samples for trial and the freight paid by receiver.Just inform us the spec you need and your courier account , we'll make arrangement in soon.

About Upass:

Upass, founded in 2008, is headquartered in New Materials Industrial Park, Qingpu District, Shanghai, and has two production bases in Taicang, Jiangsu and Chenzhou, Hunan. Now as a governing unit of China Building Waterproof Association, a vice chairman unit of Professional Committee of China Modified Plastic Association, an enterprise with Triple A credibility in China Plastic Association, not only assists the development of the relevant industries, but also upholds the conception of sustainable development by successive technological innovation. Upass so far has acquired over 100 of intellectual property rights.

UPASS will spare no effort in strengthening and improving the production, sales networks, service system to return the trust and support of customers, and look forward to working with you in a win-win future.

Company History:

Main Fields:

As a new material field, functional films are also one of the top ten key fields of Made in China 2025, and the awareness in the market is increasing. Nowadays, functional films are not only used in the construction field, special packaging, tape, label, automobile, electronics and other industries, but also in the fields of film filtration, air permeable film, graphene heating film, insulation film, Anti-UV film, biodegradable materials etc..

UPASS, as a leading domestic deep cultivator of polymer functional films, has also entered a stage of rapid development. We believe that UPASS will enter more application fields of polymer films innear future.

Quanlity Control:

1)Before the order can be confirmed finally,we would strictly check the material ,color,

dimension of the sample step by step.

2)We salesman ,also as a order follower,would trace every phase of production from the

beginning.

3)We have a QC team ,every product would be checked by them before packed.

4)We would try our best to help clients solve problems when they occurred.

After Sales Service:

Any small problem happening in our products, will be solved at the most prompt time.

We always offer relative technical support. Quick response, all your inquire will be replied

within 24 hours.

If you want to know more about our Die Cut Application PET Silicone Coated Release Liner,

welcome to contact us and visit our factory and showroom.

Cherry at your service in 24 hours ^_^

give you a best price

To order more the price will be low

save your Precious time for Purchase
