Corrosion Butyl Tapes Application Anti Corrosion Film

Ask Lasest Price
Brand Name :	Upass
Model Number :	Laminated Film
Certification :	CE, ROHS
Price :	Negotiable
Payment Terms :	T/T,L/C
Supply Ability :	200,000㎡~300,000㎡
Delivery Time :	15days

Add to Cart

Product Details
Company Profile

Corrosion Butyl Tapes Application Anti Corrosion Film

Aging Resistance Surface Material White Anti Corrosion Film

Description:

It is a surface material, use high strength cross laminated film laminated with fluorine film, make the film high strength and aging resistance.

Use white fluorine film uper side, it is VU resistance, chemical corrosion resistance, and can refelct over 85%-90% sunlight, aging resistance can be up to 25 years. The under layer is cross laminated film, high strength and tear resistance, make it the ideal surface material for anti-corrosion butyl tapes and waterproofing membranes.

Parameter:

Detection Item		Detection Method	Detection Value	Remark
Thickness	UF509	GB/T6672-2001	0.128mm	/
Width		GB/T6673-2001	/	According to customer needs
Max force	UF509	GB/T 328.9-2007	MD:324N	Rectangular spline, spline width 25mm, stretching rate: 100mm / min, fixture gauge distance: 100mm
			TD:348N
Elongation at Break	UF509		MD:406%
			TD:260%
Tensile Strength	UF509	GB/T 529-2008	MD:47N	Stretching speed:250mm/min
			TD:43N
Surface Tension		GB/T14216	≧42dyn/cm	Dyne Pen Test
Dimensional change rate	UF509	GB/T 35467-2017	MD:0.96%	90℃&24h
			TD:0.77%
Water vapor transmission rate		GB/T 21529	≦70 g/m2.24h (20um)	38℃+100%RH
				Electrolytic sensor method
Flammability grade		UL94	VTM-0	White weathering film
Aging test	PCT96	/	Yellowing index △b≤2.0,	Temperature 121 ℃, humidity 100%, air pressure 2atm, time 48h
	UV300KWh	IEC61215		The temperature of the sample is 60 ± 5 ℃, and the total exposure is 120KWh • m2, of which UVB accounts for 3% -10%.
	DH2000h	IEC61215		Temperature 85 ℃, humidity 85% R.H., 2000h
	TC400	IEC61215		Temperature －40 ℃ ～ 85 ℃, 6h / cycle, 400cycle

Application:

1. Surface Material For Anto Corrosion Tapes Application:

2. Surface Material For Anti Corrosion Waterproof Membranes Application:
